Lathe 001
| Machine | 001 |
| Dimensions of slab flooring (table), mm | 2000 x 6000 |
| The maximum mass of the workpiece to be installed, kg | 50 000 |
| Distance between posts (clearance for the protection of guides), mm | 2 600 |
| Axes | |
| Slider stroke (Z), mm | 1500 |
| Spindle head stroke (Y), mm | 1590 |
| Crossbar stroke (X), mm | 5800 |
| Spindle head | |
| Power of the electric motor of the main drive, kW | 28 |
| Spindle torque, Nm | 1400 |
| Spindle speed range, rpm | 2200 |
| Spindle taper | 50 |
| Mixes | |
| Feed limits, mm / min Z 1 ... | 2-12 000 |
| Fast travel speed, mm/min: X | 20 000 |
| Fast travel speed, mm/min: Y | 20 000 |
| Fast travel speed, mm/min: Z | 12 000 |
| Other | |
| CNC system | China |
| Chip collector type | Scraper |
| Maximum load per 1 m of table length, kg | 9000 |
| Spindle head motor power, kW | 28 |
| The total power of the electric motors installed on the machine, kW | 116 |
| Overall dimensions (L x W x H), mm | 8200x3400x2800 |
| Weight of the machine, kg not more than (together with separately located units and electrical equipment) | 32 000 |
| Cabinet protection | // |
